Brake Shoes

12 1/4" Drum Diameter

Dana Spicer

Standard Forge Cast OBSOLETE
Shoe Width = 5-1/2" FMSI No. = 4544SF
Shoe Width = 7-1/2" FMSI No. = 4607SF
Hardware Kit No. = HK1225D-TZ

---

Dana Spicer

Standard Forge Pressed Steel Early Design FT Type
Shoe Width = 5-1/2" FMSI No. = 4536SF
Shoe Width = 7-1/2" FMSI No. = 4591SF
Hardware Kit No. = LB1

---

Dana Spicer

FC Type-Commonly Called U Brake-Uses Fast Rise Camshafts
Shoe Width = 5-1/2" FMSI No. = 4536Q
Shoe Width = 7-1/2" FMSI No. = 4692Q
Hardware Kit No. = LB6

---

Dana Spicer

Standard Forge Pressed Steel Second Design FT Style
Shoe Width = 5-1/2" FMSI No. = 4536DP
Shoe Width = 7-1/2" FMSI No. = 4692DP
Hardware Kit No. = LB2

---

Dana Spicer

FC II
Shoe Width = 5" FMSI No. = 4661Q2
Shoe Width = 5-1/2" FMSI No. = 4536Q2
Shoe Width = 7-1/2" FMSI No. = 4692Q2
Hardware Kit No. = LB10

---

Dexter

Early Style
Shoe Width = 4" FMSI No. = 4700DX
Shoe Width = 5" FMSI No. = 4661DX
Hardware Kit No. = LB1

---

Dexter

PQ Style
Shoe Width = 4" FMSI No. = 4700PQ
Shoe Width = 5" FMSI No. = 4661PQ
Shoe Width = 7-1/2" FMSI No. = 4591PQ
Hardware Kit No. = LB3D

---

Eaton

EB Series
Shoe Width = 5-1/4" FMSI No. = 4536E
Shoe Width = 7-1/2" FMSI No. = 4591E
Hardware Kit No. = LB4

---

Fruehauf Propar or Delphos Axles

Standard Forge Pressed Steel Early Design FT Type
Shoe Width = 8" FMSI No. = 4649FP
Hardware Kit No. = LB5

---

Arvin Meritor

Q Shoe
Shoe Width = 7-1/2" FMSI No. = 4670Q
Hardware Kit No. = LB3

---

Dexter

Quick Change Design OBSOLETE
Shoe Width = 4" FMSI No. = 4700
Shoe Width = 5" FMSI No. = 4661
Shoe Width = 5-1/2" FMSI No. = 4536
Shoe Width = 7-1/2" FMSI No. = 4591
Hardware Kit No. =
